Add a FREE zAP2+ to any Extended Range BLACK-Comet-C-SR or BLACK-Comet-CXR-SR spectrometer or higher priced UV-VIS spectrometer this month.  One per customer.  While supplies last.

zAP2+ Electronics Upgrade
zAutomation Processor 2 upgrade provides an integrated wireless CPU with WiFi access to spectrometer and/or control of application from any smart phone. Programmable memory allows customization using popular Python language.  Once added the spectrometer runs as normal receiving power from the computer’s USB; if 5VDC power is connected directly to the BLACK-Comet the zAP2 CPU initializes and wireless communication begins. zAP2 comes pre-programmed with the latest Spectroscopy Mobile App software and StellarNet Linux Driver set. $550 value!

zAP2 Specification Sheet zAP2 User Manual

Research Grade Optical Performance – The BLACK-Comet-SR UV-VIS-NIR spectrometers utilize a Dual Blaze 40mm diameter concave grating with aberration correction to provide the best optical performance of any compact spectrometer on the market.

  • Improved spectral shapes by reducing coma and astigmatism found in plane grating spectrograph designs.
  • Stray light reduction- The spectrograph architecture does not utilize mirrors, and therefore provides the lowest possible stray light, which is especially helpful for UV applications.
  • Enhanced sensitivity- due to the spectrometers ability to reduce light scatter, especially high power UV light, the BLACK-Comet provides two to three times enhanced UV sensitivity as compared to plane grating/Czerny Turner optical configurations.
  • Uniform resolution – The concave grating produces a flat field on the CCD detector creating uniform resolution over the entire spectral range.
  • Thermal Stability- Optical bench architecture without mounting turrets and optical posts (typically in most USB spectrometers) decreases thermal expansion and contraction and increases overall system performance with temperature change

Dual blaze super range models provide wide wavelength ranges. Choose from the tables of standard models with various slit options for your choice of slit resolution. New and improved electronics with a high speed 16-bit digitizer allows for fast data acquisition and a signal to noise of 1000:1!

Ruggedized –  The detachable spectrograph assembly and control electronics are protected inside a rugged metal enclosure, suitable for portable, process, lab, and field applications.

Onboard Memory with pre-set calibrations and spectrometer settings and snap shot memory to provide instantaneous spectral image from the highly sensitive CCD with 2048.



Quote Request - BLACK-Comet zAP2+ Promotion
