MFC & MFFC Flow Cells
Liquid Sampling Accessories
Popular Applications: SpectroChemistry, Colorimetry
StellarNet Mini Flow Cells have been designed for absorbance and fluorescence spectroscopy measurements where the monitored wavelengths are longer than 210nm. There are many options available including standard and micro volumes and well as choice of material used.
MFC is a mini flow cell with 10mm optical path length with fused silica windows (optional Ultem, Plexiglas, Steel, Teflon or PEEK). Optional 2.5, 5, 10, 20, 50 and 100-mm optical path lengths.
MFC-MV is a micro volume mini flow cell with 10mm optical path length with fused silica windows (optional Ultem, Plexiglas, Steel, Teflon or PEEK). Optional 2.5, 5, 10, 20, 50 and 100-mm optical path lengths.
MFFC is a mini fluorescence flow cell that has a fiber optic cable input to send excitation energy through a fused silica window into a 2-mm inner-diameter sample compartment. Emitted energy is collected by a second fiber, oriented at 90°, that connects to a spectrometer configured for fluorescence.
MFC Options & Specifications
| MFC Description | Optical Path Length (mm) | Standard Internal Volume (ul) | Micro-Volume Internal Volume (ul) |
|---|---|---|---|
| MFC-2.5 | 2.5 | NA | 2 |
| MFC-5 | 5 | 13 | 3 |
| MFC-10 | 10 | 26 | 6 |
| MFC-20 | 20 | 52 | 12 |
| MFC-50 | 50 | 130 | 30 |
| MFC-100 | 100 | 260 | 60 |
